| Setting text on multiple layers issue |
|
Posted by: FloppaDisk - 11-12-2021, 06:52 PM - Forum: Scripting questions
- Replies (3)
|
 |
Hellois.
I'm on a mission to make an 'text atlass or sprite' ish plugin which will make the number of input characters to the power of two; combination 'sprite image'.
At the moment the code can generate one image atlass with n combinations. As a image has a limited combination spaces it will later add images as needed to make all the combinations over multiple images. But first i must understand how to set text which i hope someone would help out with.
What im struggling with is applying text. Im not able to set text on multiple layers. No matter what i do it seems like the ..WriteToCanvas() funciton only sets text to the original background layer. I'm unable to make a new layer and apply text to it.
The function ..SetAndAnchorText() is where you would modify the code to help me out if possible, or give me some good pointer as i'm been struggling for a few days to many.
Starting point:
The code works and can produce an image so you can see what i mean by atlass/sprite. Create a new 256x256 RGB_Image and run the plugin to se results. Then make a new same image and add the letter i to the end of .."Text for atlass" of the plugin. The expected result should be a whole image with text combinations in stride of two and the second should be roughly half the image with text. At the moment the code creates and error instead.
Code:
#!/usr/bin/env python
from gimpfu import *
from math import *
from time import sleep
def WriteToCanvas(image, drawable, x, y, text):
return pdb.gimp_text_fontname(
image, # IMAGE image The image
drawable, # DRAWABLE drawable The affected drawable: (-1 for a new text layer)
x, # FLOAT x The x coordinate for the left of the text bounding box
y, # FLOAT y The y coordinate for the top of the text bounding box
text, # STRING text The text to generate
-1, # INT32 border The size of the border: -1 <= border
False, # INT32 antialias Antialiasing (TRUE or FALSE)
26, # FLOAT size The size of text in either pixels or points
0, # INT32 size_type The units of specified size: PIXELS (0) or POINTS (1)
'Monospace') # STRING fontname The fontname (conforming to the X Logical Font Description Conventions)
# returns stride of 3 for characters that use kerning
def FindKerning(src):
kerning = []
idx1 = idx2 = 0
while ~idx1:
idx1 = SearchSrc(src, '(', idx2)
idx2 = SearchSrc(src, ')', idx1)
if idx1 < idx2 and abs(idx1-idx2) != 1:
kerning += [src[idx1-1]] + src[idx1+1:idx2].split(',')
src = src.replace(src[idx1:idx2+1], '', 1)
idx1 = idx2 = 0
return kerning + [src]
# return index for for instance of ..test in ..src at interval ..stride
def SearchSrc(src, test, after=0, stride=0):
x = 0
if not ~after:
return -1
if stride <= 0:
stride = 1
if after > 0:
x += after
while x < len(src):
if src[x] == test:
return x
x += stride
return -1
# ab(-1,0)cdef(-1,0)ghijk(-1,0)lmnop(-1,0)qr(-1,0)stuvwxyz01(-1,0)23456789!"#%&/()=?\*<>-_,.:;~@${}
def SetAndAnchorText(image, drawable, text, newLayer):
# sleep(3)
pdb.gimp_message(str('Ono line: \n')+str(text))
textLayer = WriteToCanvas(image, drawable, 0, 0, text)
# image.add_layer(textLayer, len(image.layers))
layer = pdb.gimp_image_merge_visible_layers(image, 1)
drawable.visible = False
if newLayer:
newLayer = gimp.Layer(image, "Background", image.width, image.height, RGB_IMAGE, 100, 3)
image.add_layer(newLayer, 0)
image.active_layer = image.layers[0]
# pdb.gimp_drawable_edit_bucket_fill(newLayer, 1, 1, 1)
# newLayer.update(0, 0, drawable.width, drawable.height)
# pdb.gimp_drawable_get_name(item)
def textAtlas(image, drawable, NotUsed, text_var, boolean_var, colorText, colorBackground, radio_var):
# ab(-1,0)cde(2,-4)fg(3,1)h
pdb.gimp_message(str('~~~~~~~~~~~~~~~~~~~~'))
kerningParams = FindKerning(text_var) # stride of 3 for chars that use kerning
text_var = kerningParams[-1] # will always be plain ..text_var
del kerningParams[-1] # remove ..text_var
# pdb.gimp_message(str('text_var: ')+str(text_var))
# pdb.gimp_message(str('kerning: ')+str(kerningParams))
# return
pdb.gimp_context_set_foreground(colorText)
pdb.gimp_context_set_background(colorBackground)
rowNumber = drawable.width/32
gridNumber = rowNumber * (drawable.height/32)
number = int(pow(len(text_var), 2))
length = len(text_var)
gimp.progress_init('The growing bar')
count = 0
wholeText = ''
tempText = ''
for char1 in text_var:
for char2 in text_var:
wholeText += char1+char2
tempText += char1+char2
count += 1
if count == gridNumber:
SetAndAnchorText(image, drawable, tempText, not text_var[-1] == char1 == char2)
# apply, merge and adjust for kerning here
tempText = ''
count = 0
if not count%rowNumber and count:
tempText += '\n'
if count:
SetAndAnchorText(image, drawable, tempText, False)
pdb.gimp_message(str('Done'))
# abcdefghijklmnopqrstuvwxyz
# ab(-1,0)cdef(-1,0)ghijk(-1,0)lmnop(-1,0)qr(-1,0)stuvwxyz01(-1,0)23456789
# ab(-1,0)cdef(-1,0)ghijk(-1,0)lmnop(-1,0)qr(-1,0)stuvwxyz01(-1,0)23456789!"#%&/()=?\*<>-_,.:;~@${}
register(
"python-fu-textAtlas",
"Make text paired utf-8'ish atlas",
"Generate an grid with n pared two character, number and/or symbol into an atlas/sprite",
"Drop Woodland", "https://github.com/TeaWave", "2021",
"Make text atlas...",
"", # type of image it works on (*, RGB, RGB*, RGBA, GRAY etc...)
[
(PF_IMAGE, "image", "takes current image", None),
(PF_DRAWABLE, "drawable", "Input layer", None),
(PF_INT8, "NotUsed", "Colors", 8),
(PF_TEXT, "text_var", "Text for atlas", "ab(-1,0)cde(2,-4)fg(3,1)h"),
(PF_BOOL, "boolean_var", "boolean name", True),
(PF_COLOR, "colorText", "Text color", (0.541, 0.831, 0.235, 1.0)),
(PF_COLOR, "colorBackground", "Background color", (0.298, 0.361, 0.576, 1.0)),
(PF_RADIO, "radio_var", "radio", "scale",
(
("Scale to fit", "scale"),
("Fill to fit", "fill")
)
)
],
[],
textAtlas, menu="<Image>/Extra") # second item is menu location
main()
|
|
|
| Tile a seamless pattern |
|
Posted by: rockinaleather - 11-12-2021, 12:42 PM - Forum: Older Gimp versions (2.8, 2.6....)
- Replies (1)
|
 |
Hey guys! I use gimp on occasion but definately an amateur at it. Im currently paying a gal to take seamless images I find on vector stock, put them together then to a certain size, with the pattern on the image being around 1" in areas. Im terrible at explaining so here's another explanation: Take said image, tile it, then scale it down. I can't for the life of me figure out how to tile an image on gimp 2.8 (only version I have). Ive googled several times but it always wants me to create my own tile image, which isn't what im trying to to. any help would be great appreciated!
|
|
|
| Macro pour flouter une zone |
|
Posted by: Gypsie38 - 11-11-2021, 04:30 PM - Forum: General questions
- Replies (1)
|
 |
Bonjour, voici ce que je souhaite : je sélectionne une zone d’une image puis je clique sur un »bouton » (qui aura été configuré pour avoir le bon flouté avec Flou gaussien) pour flouter cette zone. Merci de votre aide.
|
|
|
| Problem with drawing tablets |
|
Posted by: david - 11-11-2021, 12:13 PM - Forum: Linux and other Unixen
- No Replies
|
 |
I have had a minor problem with drawing tablets for some time - it is not a showstopper.
When I open GIMP the pen is greyed out in Configure input devices. If I then open Libreoffice Draw and do a scribble, close Draw without saving, the pen works correctly. It is no longer greyed out in input devices. It is as though GIMP is failing to load something which Draw then loads.
This has occurred in Ubuntu 20.04 and 18.04, in GIMP 28 as well as previous versions.
For me this is only a minor irritation but a solution may help others.
|
|
|
| .TIFF issues after overwritting |
|
Posted by: Hutch_CAD - 11-10-2021, 06:12 PM - Forum: General questions
- Replies (2)
|
 |
using bentley microstation which often has .tiff attachments (These are engineering drawings that were hand drawn and scanned into the system over the years as industry went more CAD based). We generally use GIMP to erase elements from the drawing, use {file -> overwrite fileName.tiff} then open the file in microstation and draw in the CAD elements. The tiff and DGN files are located in the same file location, microstation opens fine until I use GIMP and overwrite the tiff. when I try to open the CAD file the program produces an error and closes. I can change the .tiff file name in which case the .DGN no longer references the file (normally attached as a Raster?) and the CAD will open without the .tiff.
A get around I can use (though it messes up the presentation) is to open the .tiff in paint, hit save, and close it. then it's normal operating procedure. What's happening here? is GIMP changing the .tiff format? everyone else in my department has zero trouble with this so I know how it SHOULD work, but it just doesn't. tackled the issue with IT and microstation support and it appears to be a GIMP issue.
Any and all help/suggestions are welcome! thanks folks.
|
|
|
|
