  Problems with the brushes since the update
Posted by: solnischka78 - 01-31-2024, 07:35 PM - Forum: General questions - Replies (2)

Hello dear community,

I am new in this forum. I use a Huion Tablet H950P, since the update to Gimp 2.10.36 my lines look like the screenshot. Very pixelated. I haven't done much with brushes in Gimp so far, however the strokes look terrible compared to results in other programs. Can anyone help me?



Attached Files Thumbnail(s)

Print this item

Python Try to transform a python script to go/back/and forth between Darktable and GIMP
Posted by: PixLab - 01-31-2024, 05:31 AM - Forum: Scripting questions - Replies (2)

The original script is for LightZone and GIMP, which works nicely, from GIMP to LZ and back to GIMP

So my changes works nicely from GIMP to Darktable, but to get back from Darktable to GIMP again, I got an error



Any idea, help? I can't think anymore my head gets narrow vision now and is on fire Big Grin

the code I did some change for Darktable:

Code:
#!/usr/bin/env python

'''
Lightzone.py
call LightZone passing the active layer as a temp file.

Author:
Rob Antonishen
Modified by
Partha Bagchi
Modified by Martin Pohl
Modified by
Stefano Azzi
Modified by
Masahiro Kitagawa

Version:
0.8c Made it compatible with Windows, macOS, and Linux
0.8b Made it specific for LightZone
0.8 Made it specific to Nik Collection
0.7 fixed file save bug where all files were png regardless of extension
0.6 modified to allow for a returned layer that is a different size
   than the saved layer for
0.5 file extension parameter in program list.
0.4 modified to support many optional programs.

this script is modelled after the mm extern LabCurves trace plugin
by Michael Munzert http://www.mm-log.com/lab-curves-gimp

and thanks to the folds at gimp-chat has grown a bit ;)

License:

This program is free software; you can redistribute it and/or modify
it under the terms of the GNU General Public License as published by
the Free Software Foundation; version 3 of the License.

This program is distributed in the hope that it will be useful,
but WITHOUT ANY WARRANTY; without even the implied warranty of
MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
GNU General Public License for more details.

The GNU Public License is available at
http://www.gnu.org/copyleft/gpl.html

'''

from gimpfu import *
import shlex
import subprocess
import os, sys
import tempfile
from shutil import copyfile

def gimp_log( text ):
    pdb.gimp_message( text )

def plugin_main( image, drawable, visible ):
 pdb.gimp_image_undo_group_start(image)

 # Copy so the save operations doesn't affect the original
 if visible == 0:
   # Save in temporary.  Note: empty user entered file name
   temp = pdb.gimp_image_get_active_drawable(image)
 else:
   # Get the current visible
   temp = pdb.gimp_layer_new_from_visible(image, image, "Darktable")
   image.add_layer(temp, 0)

 buffer = pdb.gimp_edit_named_copy(temp, "ShellOutDTTemp")

 #save selection if one exists
 hassel = pdb.gimp_selection_is_empty(image) == 0
 if hassel:
   savedsel = pdb.gimp_selection_save(image)

 tempimage = pdb.gimp_edit_named_paste_as_new(buffer)
 pdb.gimp_buffer_delete(buffer)
 if not tempimage:
   raise RuntimeError
 pdb.gimp_image_undo_disable(tempimage)

 tempdrawable = pdb.gimp_image_get_active_layer(tempimage)

 tempfilename = os.path.join(tempfile.gettempdir(), "ShellOutDTTempFile.tif" )


 # !!! Note no run-mode first parameter, and user entered filename is empty string
 pdb.gimp_progress_set_text ("Saving a copy")
 pdb.gimp_file_save(tempimage, tempdrawable, tempfilename, tempfilename)

 # Build command line call
 if sys.platform.startswith('win'):
   progtorun = "\"" + os.environ["ProgramW6432"] + "\\darktable\\darktable.exe\""
 elif sys.platform.startswith('darwin'):
   progtorun = "open -W -a \"darktable.app\""
 elif sys.platform.startswith('linux'):
   progtorun = "\"darktable\""
 command = progtorun + " \"" + tempfilename + "\""
 args = shlex.split(command)

 # Invoke external command
 pdb.gimp_progress_set_text ("calling Darktable...")
 pdb.gimp_progress_pulse()
 child = subprocess.Popen(args, shell=False)
 child.communicate()

 # put it as a new layer in the opened image
 try:
    darktablefile = os.path.join(tempfile.gettempdir(), "ShellOutDTTempFile.tif")
    copyfile( darktablefile, tempfilename )
    newlayer2 = pdb.gimp_file_load_layer(tempimage, tempfilename)
 except:
   RuntimeError

 tempimage.add_layer(newlayer2,-1)
 buffer = pdb.gimp_edit_named_copy(newlayer2, "ShellOutDTTemp")

 if visible == 0:
   drawable.resize(newlayer2.width,newlayer2.height,0,0)
   sel = pdb.gimp_edit_named_paste(drawable, buffer, 1)
   drawable.translate((tempdrawable.width-newlayer2.width)/2,(tempdrawable.height-newlayer2.height)/2)
 else:
   temp.resize(newlayer2.width,newlayer2.height,0,0)
   sel = pdb.gimp_edit_named_paste(temp, buffer, 1)
   temp.translate((tempdrawable.width-newlayer2.width)/2,(tempdrawable.height-newlayer2.height)/2)

 pdb.gimp_buffer_delete(buffer)
 pdb.gimp_edit_clear(temp)
 pdb.gimp_floating_sel_anchor(sel)

 #load up old selection
 if hassel:
   pdb.gimp_selection_load(savedsel)
   image.remove_channel(savedsel)

 # cleanup
 os.remove(tempfilename)  # delete the temporary file
 gimp.delete(tempimage)   # delete the temporary image
 os.remove( darktablefile )     # delete the locally created LZ file
 # Note the new image is dirty in Gimp and the user will be asked to save before closing.
 pdb.gimp_image_undo_group_end(image)
 gimp.displays_flush()


register(
       "python_fu_Darktable",
       "Call Darktable",
       "Call Darktable",
       "Rob Antonishen",
       "Copyright 2011 Rob Antonishen",
       "2011",
       "<Image>/Filters/Photo Editors/Darktable",
       "RGB*, GRAY*",
       [ (PF_RADIO, "visible", "Layer:", 1, (("new from visible", 1),("current layer",0))),
       ],
       [],
       plugin_main,
       )

main()


Original code of Lightzone.py
Code:
#!/usr/bin/env python

'''
Lightzone.py
call LightZone passing the active layer as a temp file.

Author:
Rob Antonishen
Modified by
Partha Bagchi
Modified by Martin Pohl
Modified by
Stefano Azzi
Modified by
Masahiro Kitagawa

Version:
0.8c Made it compatible with Windows, macOS, and Linux
0.8b Made it specific for LightZone
0.8 Made it specific to Nik Collection
0.7 fixed file save bug where all files were png regardless of extension
0.6 modified to allow for a returned layer that is a different size
    than the saved layer for
0.5 file extension parameter in program list.
0.4 modified to support many optional programs.

this script is modelled after the mm extern LabCurves trace plugin
by Michael Munzert http://www.mm-log.com/lab-curves-gimp

and thanks to the folds at gimp-chat has grown a bit ;)

License:

This program is free software; you can redistribute it and/or modify
it under the terms of the GNU General Public License as published by
the Free Software Foundation; version 3 of the License.

This program is distributed in the hope that it will be useful,
but WITHOUT ANY WARRANTY; without even the implied warranty of
MERCHANTABILITY or FITNESS FOR A PARTICULAR PURPOSE.  See the
GNU General Public License for more details.

The GNU Public License is available at
http://www.gnu.org/copyleft/gpl.html

'''

from gimpfu import *
import shlex
import subprocess
import os, sys
import tempfile
from shutil import copyfile

def gimp_log( text ):
    pdb.gimp_message( text )

def plugin_main( image, drawable, visible ):
  pdb.gimp_image_undo_group_start(image)

  # Copy so the save operations doesn't affect the original
  if visible == 0:
    # Save in temporary.  Note: empty user entered file name
    temp = pdb.gimp_image_get_active_drawable(image)
  else:
    # Get the current visible
    temp = pdb.gimp_layer_new_from_visible(image, image, "LightZone")
    image.add_layer(temp, 0)

  buffer = pdb.gimp_edit_named_copy(temp, "ShellOutTemp")

  #save selection if one exists
  hassel = pdb.gimp_selection_is_empty(image) == 0
  if hassel:
    savedsel = pdb.gimp_selection_save(image)

  tempimage = pdb.gimp_edit_named_paste_as_new(buffer)
  pdb.gimp_buffer_delete(buffer)
  if not tempimage:
    raise RuntimeError
  pdb.gimp_image_undo_disable(tempimage)

  tempdrawable = pdb.gimp_image_get_active_layer(tempimage)

  tempfilename = os.path.join(tempfile.gettempdir(), "ShellOutTempFile.tif" )


  # !!! Note no run-mode first parameter, and user entered filename is empty string
  pdb.gimp_progress_set_text ("Saving a copy")
  pdb.gimp_file_save(tempimage, tempdrawable, tempfilename, tempfilename)

  # Build command line call
  if sys.platform.startswith('win'):
    progtorun = "\"" + os.environ["ProgramW6432"] + "\\LightZone\\LightZone.exe\""
  elif sys.platform.startswith('darwin'):
    progtorun = "open -W -a \"LightZone.app\""
  elif sys.platform.startswith('linux'):
    progtorun = "\"lightzone\""
  command = progtorun + " \"" + tempfilename + "\""
  args = shlex.split(command)

  # Invoke external command
  pdb.gimp_progress_set_text ("calling LightZone...")
  pdb.gimp_progress_pulse()
  child = subprocess.Popen(args, shell=False)
  child.communicate()

  # put it as a new layer in the opened image
  try:
    lightzonefile = os.path.join(tempfile.gettempdir(), "ShellOutTempFile_lzn.jpg")
    copyfile( lightzonefile, tempfilename )
    newlayer2 = pdb.gimp_file_load_layer(tempimage, tempfilename)
  except:
    RuntimeError

  tempimage.add_layer(newlayer2,-1)
  buffer = pdb.gimp_edit_named_copy(newlayer2, "ShellOutTemp")

  if visible == 0:
    drawable.resize(newlayer2.width,newlayer2.height,0,0)
    sel = pdb.gimp_edit_named_paste(drawable, buffer, 1)
    drawable.translate((tempdrawable.width-newlayer2.width)/2,(tempdrawable.height-newlayer2.height)/2)
  else:
    temp.resize(newlayer2.width,newlayer2.height,0,0)
    sel = pdb.gimp_edit_named_paste(temp, buffer, 1)
    temp.translate((tempdrawable.width-newlayer2.width)/2,(tempdrawable.height-newlayer2.height)/2)

  pdb.gimp_buffer_delete(buffer)
  pdb.gimp_edit_clear(temp)
  pdb.gimp_floating_sel_anchor(sel)

  #load up old selection
  if hassel:
    pdb.gimp_selection_load(savedsel)
    image.remove_channel(savedsel)

  # cleanup
  os.remove(tempfilename)  # delete the temporary file
  gimp.delete(tempimage)   # delete the temporary image
  os.remove( lightzonefile )     # delete the locally created LZ file
  # Note the new image is dirty in Gimp and the user will be asked to save before closing.
  pdb.gimp_image_undo_group_end(image)
  gimp.displays_flush()


register(
        "python_fu_Lightzone",
        "Call LightZone",
        "Call LightZone",
        "Rob Antonishen",
        "Copyright 2011 Rob Antonishen",
        "2011",
        "<Image>/Filters/Photo Editors/LightZone",
        "RGB*, GRAY*",
        [ (PF_RADIO, "visible", "Layer:", 1, (("new from visible", 1),("current layer",0))),
        ],
        [],
        plugin_main,
        )

main()

Print this item

  hand drawn line effect
Posted by: Robpared - 01-30-2024, 07:54 PM - Forum: General questions - Replies (22)

New here (architect doing building illustrations) and searched but could not find anything. New to GIMP and trying to use an effect similar to Photoshop ripple effect which I used to convert vector exported lines into a "jiggled" effect to make them look hand drawn (CAD drawing to render like traced by hand). Not looking for photo to pencil sketch or anything like that. The ripple effect in Photoshop is pretty straight forward, only choosing percent of "jiggle" and medium or large effect. The ripple filter in GIMP does not achieve anything like the photoshop ripple. The imported images are typically black and white. Looked across the web and everything is about converting photos into a pencil like sketch but the lines are not "squiggly".
Help please  Huh

Print this item

  Upscaling photos with Upscayl
Posted by: denzjos - 01-30-2024, 03:51 PM - Forum: Other graphics software - No Replies

Upscayl is a free and open source AI image upscaling software that can enlarge and enhance low resolution images using deep learning
https://www.upscayl.org

Detail eye after scaling :


Print this item

  Real-ESRGAN GUI upscaling
Posted by: denzjos - 01-30-2024, 02:17 PM - Forum: Other graphics software - Replies (7)

Real-ESRGAN GUI, a graphic interface of Real-ESRGAN an image magnification tool.
https://sourceforge.net/projects/real-es...ui.mirror/
https://github.com/bycloudai/Real-ESRGAN-Windows
A test :
original :

upscaled


Print this item

  Croping background
Posted by: couldbeworse - 01-30-2024, 12:22 AM - Forum: General questions - Replies (4)

The attached screenshot shows an image I am attempting to use as a logo for a website. However, whenever I add the image the banner increases in height. After playing around with the code and not being able to figure it out, I can only assume it's because of the background size. I've already scaled the image as large as I can. Is it possible to crop the red portion of the screenshot, so all I see is the image and none of the background?



Attached Files Thumbnail(s)

Print this item

  What is the "Levels>Auto Input Levels" operation actually doing?
Posted by: ajax - 01-29-2024, 06:07 PM - Forum: General questions - Replies (11)

Unfortunately, the documentation I've been able to find says little to nothing about what is actually being done to the image when the "Auto Input Levels" button is selected on the "Color>Levels" tool.  The GIMP User Manual section says only "Auto: Performs an automatic setting of the levels." which is applied to All Channels.

This question arises as a result of what I'd call quite remarkable results that are produced by the Auto Input Levels when NOT being able to come even close to getting the same results by using the other available (e.g. manual) options for making adjustments.

The related image files were produced by scanning some pretty old film strips (35mm negatives).  For example, when the scanner produced image file is opened in GIMP and a jpg image is created before making any edits the result is as follows:

[Image: Neg101.Original.jpg]


Then when doing nothing other than applying "Color>Levels>Auto Input Levels" the similar jpg image file that results follows:

[Image: Neg101.AutoLevel.jpg]

To the extent that it might matter a screenshot of the tool ("Adjust Color Levels") values associated with the original image file shown above is as follows:

[Image: AdjustColorLevelsWindow.jpg]

Note:  When the "Auto Input Levels" button is selected the image is changed quite dramatically in this case but nothing gets changed/updated within the "Adjust Color Levels" window.

These examples are derived from using GIMP 2.20.36 on Windows.

My thinking is that "Auto" means the tool is doing the same things described in the documentation that I should be able to do manually.  One might even think that the window which shows changes when made manually could be updated to reveal what changes that are being made automatically.  Of course this is NOT possible if "Auto Input Levels" is doing something different than what a user can do on there own.  If so, it would be nice to at least know what kind of things are possible when selecting "Auto Input Levels" that cannot be done otherwise.

Print this item

  Left menu pane vanished
Posted by: SpanishRed - 01-29-2024, 02:05 AM - Forum: General questions - Replies (2)

The lefthand menu pane of my software vanished while I was busy working with GIMP, so clearly I pushed something I should not have pushed. I've tried:

  • Pushing tab
  • Cnt B
  • Looking for an option in the "View" menu
  • Looking for an option in the "windows" menu.
Nothing works. Then I tried uninstalling and reinstalling the software, but it won't uninstall. I've tried uninstalling from the apps and features menu as well as from the start menu.

Print this item

  All my color blendings are tending towards brighter values in all images
Posted by: Ellye - 01-27-2024, 05:03 AM - Forum: General questions - Replies (4)

Suppose I have a pure black (#000000) layer and a pure white (#FFFFFF) layer.
They are one on top of the other, both with normal blending. The one above is 50% opacity.

I'd expect that the resulting color would be a midpoint gray (#7F7F7F). And I'm pretty sure that's what I used to get on GIMP until recently, and it's still what I get on other softwares.
Instead, I'm getting #BCBCBC - a far brighter color.

This is not just about layer blending either - any brush with some kind of transparency or anything like that - the result of mixing colors always come up brighter than I'd expect.

I tried both "Perceptual Gamma" and "Linear Light" modes, no change.

Video demonstrating (I compare with Paint.Net on it, but the result there is the same on any other software aside from GIMP - from Photoshop to html rendering in web browsers):
https://www.youtube.com/watch?v=OfAXikmC...e=youtu.be

Print this item

  What happens to metadata in GIMP?
Posted by: andreo - 01-26-2024, 06:55 PM - Forum: General questions - Replies (5)

I was wondering what happens to metadata in Gimp. I was having fun playing with some programming languages to create an image editor. I understand that in broad terms the structure is this:

I have a .jpg photo that I want to edit, I upload it to the editor, the editor generally uses an external library to read the .jpg file; it takes this file, decompresses it, isolates the bits relating to the actual image which will form an array of pixels of the exact dimensions of the image that will be shown on the screen.


At this point each editor will have its own functionality for editing the photo.


Once you have achieved the desired result you can export the photo again as .jpg. The edited pixel array is taken and compressed again into a .jpg file via an external library.


I wanted to understand what happens to the metadata in this process in Gimp. I tried to read the Gimp source code but I didn't understand.


I'm interested in understanding well what the final exported .jpg image is made of. If it is composed of the compressed pixel array of the edited image + some metadata created by Gimp useful for the final file (Such as resolution and size) + any metadata from the original file that Gimp recognizes and copies into the new one (Asking you during export if you want to keep them or not and allowing you to modify them).


Or could it happen that Gimp adds metadata present in the original photo to the final .jpg but does not recognize it and does not show it in the metadata viewer or editor?


If anyone knows any places within the Gimp code where I can understand this, it would be very useful for me.

Print this item
