| Cropping and slicing a path |
|
Posted by: Ottia Tuota - 10-09-2020, 11:31 AM - Forum: Extending the GIMP
- Replies (29)
|
 |
I made a plugin to crop a path, similar to cropping an image or a layer. I don't know any such tool in Gimp previously, but what I know about Gimp is very limited, so please enlighten me if I am wrong.
Actually I made four plugins, two for cropping, two for slicing:
- Crop path by convex polygon
- Crop path by rectangle
- Slice path by guides
- Slice path by lines
Numbers 2 and 3 are the main plugins, that is, I expect them to be the most used. The other two came as by-products.
To get the plugins, go to Cropping and slicing a path, scroll to the bottom, and click the download button. You get a zip file. Unzip it and place the one file it contains (crop_path.py) in your user's plug-ins folder. Then (re)start Gimp.
To invoke the plugins, go to the Paths tab, right-click some path and follow the link
Tools > Cropping and slicing > ...
I explain now the plugins. They are very simple to use (quite an achievement from me).
Crop path by rectangle takes as input a path (the right-clicked one) and it allows four choices for the cropping rectangle:
- a rectangular selection
- four guides (two horizontal, two vertical)
- image (canvas)
- the active layer.
The first option (selection) allows in fact any selection, not only rectangular, but only its bounding box is used. In this sense it works just in the same way as the usual tool Image > Crop to selection works for images.
The second option (guides) requires that no other guides exist.
Crop path by convex polygon works similarly except that instead of a rectangle the cropping region is a convex polygon. The polygon is inputted as a path: closed, with straight edges, enclosing a convex region. ("Convex" means that all corners jut outwards.) Of the polygon path only anchors are taken into account; all curviness is ignored.
Then the two slicing plugins:
Slice path by lines takes as input two paths. One is the source path to be sliced (the right-clicked one), and the other is supposed to be a set of straight line segments, one line segment per stroke. Of each stroke the first two anchors are read and used to determine a line. You can think that each stroke is supposed to be a 2-anchor path, a straight line segment. Note that the line segments may be short, but the plugin sees and uses them as full infinite lines.
If the slicing path has only one stroke (only one slicing line), the source path is split into two parts. This is the situation in the following picture. For this picture, I moved the two halves of the result slightly apart just so that you can see what happened.
What happens here is more precisely the following. The path is splitted into two parts. Two new paths are created: if the original path has name 'path', the new ones will probably be 'path|slice' and 'path|slice #1'. If either of them is empty, it is discarded (not inserted in Gimp). But in some cases an additional new path is created. Namely, if the original path contains straight line segments which lie flat on the slicing line, there is no way to tell to which side they belong, so they are collected as a separate additional new path.
In the next picture the slicing path consists of three strokes (three slicing lines). Again I moved the sliced parts a little just to show the effect.
Slice path by guides works quite similarly except that the slicing lines are guides. You have the choice to use all guides in the image, or only horizontal guides, or only vertical guides.
A word of warning: The running time grows fast with the number of slicing lines (or guides). That is why I prevented the usage of more than 8 lines. Another advantage of this is that the number of created new paths also grows fast, and it is good to have some limit. If you want to change that number 8, find and edit in the code the line
MAX_SLICE_LINES = 8 # Maximum number of slicing lines allowed
But please, do not go over 10.
If you find some case where the plugins act strangely, please report. The code is a little messy, I admit, and I may have missed something.
|
|
|
| Gimp 2.10.14 - text editor changing text size |
|
Posted by: Accessdenied - 10-09-2020, 08:18 AM - Forum: General questions
- Replies (6)
|
|
Hi!
Created simple business card. Some text boxes, one image. Saved.
Now opened it and if I click on Text tool and then on text, it changes size. Cannot figure out how to edit text without damaging it's size. In layers it show as A - I guess as text layer. Right click on layer and Edit on canvas gives the same result.
|
|
|
|
| gimp 2.10.22 |
|
Posted by: vpkumar - 10-09-2020, 03:18 AM - Forum: General questions
- Replies (3)
|
|
I downloaded and ionstalled the latest Gimp 2.10.22 in windows 64.
However now I find all my scripts -Fu and python plug in are greyed out.
How do I restore all these scripts and plugins
I am sorry I found out that this was because I had not opened any imgae in Gimp. Once I opened an image everything was OK.
|
|
|
|
| GIMP 2.10 - Trouble Painting or Cloning On Top of Alpha |
|
Posted by: TMORT - 10-09-2020, 01:14 AM - Forum: General questions
- Replies (4)
|
|
I have picture I'm working on with several layers. There is an area of alpha, and a border around it on another layer and another layer has an image of some leaves. I'd there is a gap of alpha between the colored border and the leaves. I'd like paint or clone over the gap of alpha.
I've tried adding another layer, raising and lowering layers. It is just locked somehow. I've tried pressing the little chekerboard in the layers tool panel for each of them.
I've used GIMP for a number of years, and a number of features and tools, but only do a few now and then. I never really use it enough to get proficient or retain how do things.
|
|
|
|
| Copy channel from one image to another image. |
|
Posted by: Krikor - 10-08-2020, 06:35 PM - Forum: General questions
- Replies (6)
|
 |
How can I to copy channel from one image to another image?
I have two images open. In one of them I created channels which I want to use in the second image as well.
How I do:
I select one of the created channels - Channel for selection.
From this selection I create a path - Select - To Path.
In the Paths tab, drag this created path over the thumbnail of the second image.
I open the second image, and now I reverse the operation, select the path and create a channel from that selection.
Is there another, faster and more efficient way to copy channels from one layer to another?
Thank you.
|
|
|
|
| can't get two blacks to match |
|
Posted by: ottenm - 10-08-2020, 03:50 PM - Forum: General questions
- Replies (2)
|
|
In this PNG of 5 tally marks, the 5th one (going across) is visibly blacker & shinier than the others. I'd like it to match the other 4, but I'm struggling to figure out what the difference is.
Just grabbing pixels with the eye-dropper both sets seem about the same, a mix of solid black and colors that are close to black. I thought it might be the alpha values, but I tried Layer > Transparency > Threshold Alpha and at 99% there's still a noticeable difference between the pixels that are left.
Any help greatly appreciated.
https://ibb.co/T1DRhTH
|
|
|
|
| Changing to a solid color |
|
Posted by: RawlinsCross - 10-07-2020, 07:25 PM - Forum: General questions
- Replies (2)
|
|
Good day everyone,
I have an image of a rain coat that I'd like to fill in with solid color. You can see (link below) that it's a funky little design, but I'd like to fill it all in with a solid color. Maybe leave the face alone but if that's too hard, then it can be filled in as well.
This is my real first foray into GIMP. It obviously is very complicated and any start-up advice would be certainly appreciated. I figure this one would be good to start off on?
Picture of Raincoat
|
|
|
|
|
